Mars Series
Mars A2
Item No.: OX-5A2 / OX-8A2 / OX-10A2
Specification
| Item No. |
OX-5A2 |
OX-8A2 |
OX-10A2 |
| Delivery Rate (LPM) |
0.5-5 |
2~8 |
2~10 |
| Output Pressure (KPa) |
58 ± 6 ( 8.5± 0.5 psi) |
80 ± 8 ( 12 ± 1 Psi) |
80 ± 8 ( 12 ± 1 Psi) |
Electrical Requirement
(Voltage/Hz) | 110VAC , 220VAC 50/60Hz | 110VAC , 220VAC 50/60Hz | 110VAC , 220VAC 50/60Hz |
| Purity (%) |
93±3(0.5-5.0 L) | 93±3(2-8 L) |
93±3 (2-9 L)
90±3 (10 L) |
| Power Consumption (Watt) |
300 (Aver.) |
450 (Aver.) |
580 (Aver.) |
| Noise Level dB(A) |
front 1 M < 42 |
front 1 M < 47 |
front 1 M < 50 |
| Dimensions (mm) |
368 (L) x 342(W) x 572 (H) |
368 (L) x 342 (W) x 572 (H) |
368 (L) x 342 (W) x 572 (H) |
| OCI ( Optional ) |
YELLOW: 82% below
RED: 70% below |
YELLOW: 82% below
RED: 70% below |
YELLOW: 82% below
RED: 70% below |
| Flowmeter |
Float / Digital |
Float / Digital |
Float / Digital |
| Warranty |
3 Years |
2 Years |
1 Years |
