Mercury Series
Continuous & Pulse dose
Item No.: OX-2A
.jpg)
0-0
Specification
| Oxygen Concentration | 87%-96% at all settings |
| Flow Settings and Pulse Volumes | Pulse Mode 1-12 Settings = 6 ml- 72 ml; +/- 15% or 4 ml, whichever is greater (Average of 20 consecutive breaths) Equal to 6 liters in Continuous mode. Continuous Mode 0.5-2 Liter , whichever is greater (3 minute running average) Note: Max recommended flow is 2 LPM (at nominal outlet pressures of 0 and 7 kPa). |
| User Interface | Power switch, Push buttons, back-light liquid crystal display (LCD) |
| Dimensions | 200 (L) X 230(W) X 325(H)mm |
| Weight | 5.4Kg |
| Sound Level |
46 dBA max. at Nominal Continuous Mode Setting of 2 Front 1M |
| Audio Alarm | 50 decibels (nominal) at 39 in. (1 m) |
| Outlet Pressure | 8.5 psi +/- 0.5psi |
| *Based on an atmospheric pressure of 14.7 psi (101 kPa) at 70°F (21°C) |
